City of Fort Bragg

A city address is usually permitted by the city, not the county — but not always, and some authorities keep building and hand electrical to someone else. Getting this wrong costs the whole submittal, because every requirement below belongs to whoever actually holds jurisdiction. Check the overlays in the same pass: an HOA, a historic district, a windstorm certification or a system-size cap can reshape the design, and all of them are cheaper to find now than after the array is laid out.

• Is this authority the AHJ for residential solar at this address? Yes, as titleholder -- but FBMC 15.04.030 defines the City's own 'Enforcement Agency' as the City's Building Inspection Dept 'or designated department or entity,' and in practice Mendocino County Planning & Building Services performs building/electrical plan review and inspection for Fort Bragg addresses from its own Fort Bragg field office. See jurisdiction block. 85% · municipal code
• What does this authority permit itself, and what does it delegate? Delegated 85% · department page
• Is a permit required for a residential rooftop PV system? Yes -- a Building Permit is required for residential rooftop PV; the County's own building permit application (used for Fort Bragg addresses) has a dedicated 'Photovoltaic' checkbox under 'Mark All That Apply.' 95% · department-hosted permit application form
• Is there a separate electrical permit, or is it combined? Combined -- a single Building Permit covers the structural and electrical (CEC 690/705) scope of a residential PV install; no separate stand-alone electrical permit is described for PV in the applicable handout or policy. 78% · department handout (fetched via Wayback capture, dated content confirmed 'Expedited Residential Rooftop Photovoltaic Systems Plan Review, Fees, and Inspections'
• Is a HOA or architectural approval required first? No -- neither the City's own code nor the County's PV submittal documents require HOA or architectural approval as part of the building-permit process itself. (California Civil Code Section 714 separately limits HOA authority to block solar statewide.) 55% · published checklist
• Is there a historic-district review? No, for eligible systems -- County Ordinance 4530 (adopted 19 Dec 2023, applicable within the Coastal Zone, which includes Fort Bragg) exempts an 'Eligible Solar Energy System' (roof-mounted, on an existing legally-constructed building, not needing certain federal/state resource permits) from 'all discretionary review... and from review by the Planning Division' -- which covers Fort Bragg's own Local Coastal Program design/historic review as well as the County's Coastal Zone review, though the fact sheet does not name a specific 'Historic Review Board' by title. 65% · department fact sheet, citing Ord. No. 4530 (19 Dec 2023)
• Is a wind or windstorm certification required? No windstorm/wind-zone certification requirement (no TDI-style program) was found; wind uplift for rooftop PV is instead handled through the Structural Criteria anchor-spacing/fastener tables (Wind Exposure C/D distinctions). 60% · department handout (Structural Criteria)
• Is a Specific Use Permit or Council approval ever required? No, for qualifying systems -- the 2015 PV Toolkit guide states 'Planning review IS NOT required for solar PV installations of this size' (<=10kW rooftop), and Ordinance 4530 separately exempts eligible rooftop solar from discretionary Coastal Zone/Planning Division review. No Council or Specific Use Permit process was found for qualifying residential PV. 75% · department handout
• Is there a system-size cap on residential generation? No hard cap on residential system size was found; 10kW AC is only the eligibility threshold for the expedited/over-the-counter review track (Eligibility Checklist item A). Larger systems are not prohibited, they simply do not qualify for the fast-track process and go through full plan review with PE-stamped drawings. 65% · department handout (Eligibility Checklist, embedded)

Several authorities require the electrical permit to be pulled by a licensed electrician, or require the contractor to be registered with them BEFORE applying. Registration is not same-day. This is second on the list rather than fourth because it is the step most likely to stop the job before the drawings matter.

• Who is allowed to pull the electrical permit? Either 85% · department-hosted permit application form
• Must the contractor be registered with this authority before applying? No separate contractor-registration step beyond standard CSLB licensing was found. 55% · department-hosted permit application form
• Is a homeowner permitted to self-install and self-permit? Yes -- the Building Permit Application includes a full 'OWNER/BUILDER DECLARATION' section under penalty of perjury for owner-builders who are exempt from the Contractors' State License Law. 90% · department-hosted permit application form

Almost everywhere wants a site plan, a one-line or three-line electrical diagram, equipment cut sheets with listings, and a structural attachment detail. Build it against the published checklist rather than the last jurisdiction you worked in — the checklist is what the reviewer marks against.

• What documents make up a complete submittal? Completed Eligibility Checklist; an Electrical Plan (or Standard Electrical Plan/PV Toolkit Doc #3-4 for systems <=10kW); a Roof/Site Plan showing panel layout, fire classification, access pathways and label locations; a Structural Plan (or the Structural Criteria checklist, PV Toolkit Doc #5, or full PE-stamped structural drawings if that checklist fails); and the completed Building Permit Application. 88% · department handout
• How many copies, and in what format? Over-the-counter: 1 completed permit application + 1 copy of an 8.5x11 plot/site plan. 'Other' (non-OTC) projects: 3 copies of construction plans, plus 2 copies of Title 24 energy compliance and 2 copies of wet-stamped engineering calculations where applicable. 85% · published checklist
• Is a site plan required, and what must it show? Yes -- a roof/site plan is required showing panel/module layout, north arrow, lot dimensions, distance from property lines to structures, PV fire classification, code-compliant access pathways, and locations of required labels/disconnects. 90% · department handout
• Is a one-line / three-line diagram required? Yes -- a one-line diagram of the complete system, including all components and wire sizes, is a required electrical-plan element. 92% · department handout
• Are string and conductor calculations required? Yes -- total number of modules, modules per string, total strings, conductor type/size, conduit type/size and number of conductors per conduit section must all be specified. 88% · adopted department policy (Building Policy 14, eff. 13 Mar 2026)
• Is a structural PE stamp required, and at what threshold? Rooftop: a CA-licensed structural/civil engineer's stamp is required only if the system fails the Structural Criteria checklist (module weight >4 psf PV/5 psf thermal, array covering >half the roof, anchor spacing beyond the Table 1 limits, roof in Wind Exposure D -- defined to include sites 'within 200 yards of the ocean or large coastal bay,' which is directly relevant to Fort Bragg's oceanfront/coastal parcels -- more than one roof covering, non-flush mounting, etc). Ground-mount: an engineer's stamp is required whenever the array exceeds 7 feet in height. 88% · department handout (PV Toolkit Document #5, Structural Criteria)
• Is an electrical PE stamp required, and at what threshold? No PV-specific electrical PE-stamp threshold was found; the only engineer/licensed-contractor trigger identified is general (not solar-specific): any new electrical service panel rated over 200A requires line drawings from an electrical engineer or CA-licensed electrical contractor. 65% · adopted department policy (Building Policy 2, eff. 10 Mar 2026)

Most authorities now take the whole application through a portal, and several states cap or constrain what a residential solar permit may cost. Check whether plan check is billed separately before you quote the job.

• Which permit portal does this authority use? e-TRAKiT (etrakit.mendocinocounty.org) -- the County's online permit portal; also accepted in person at the County's own Fort Bragg office (752 South Franklin St). 85% · portal landing page
• Can the whole application be completed online? Largely yes for the County-administered building/electrical permit -- applications 'can be submitted in person or electronically' and may be approved 'over the counter electronically' per the Expedited PV handout; full self-service payment/inspection-scheduling could not be independently confirmed. 55% · department handout
• What does a residential solar permit cost? Tension between two County documents: the still-linked 2015 PV Toolkit #1 Application Guide states plainly, 'The minimum fee on a rooftop solar installation project is $83.00 and is based on the project valuation. The total permit fees, however, will not exceed $500.00.' The newer (current) Expedited handout that has otherwise superseded much of that 2015 guide's content just states 'Fees: To be in compliance with CA State AB 1414' with no dollar figure. 55% · department handout (PV Toolkit Document #1, dated '2015 Application Guide' in its own footer, still linked live)
• How is the fee calculated? Valuation-based, per the Board of Supervisors' annually-adopted Master Fee Schedule; some structure types are billed by square footage instead, per department procedure. 70% · department procedure (image-only PDF, OCR'd by me with tesseract)
• Is there a separate plan-check fee? Yes -- a distinct Plan Check fee line exists, separate from the Basic Construction fee. 80% · department procedure (image-only PDF, OCR'd by me)

Interconnection is a separate process from the permit and usually the longer pole. Where the utility does not depend on the permit being issued, running both at once is the single biggest saving available on a residential job.

• What is the stated plan-review turnaround? Eligible/expedited rooftop PV (<=10kW meeting the Eligibility Checklist): over-the-counter same day when staff is available, otherwise reviewed within 1-3 days. Non-expedited permits generally take longer per standard plan-check queue (not solar-specific figure located for Fort Bragg). 82% · department handout
• How long is an issued permit valid before it expires? Under the City's own current code (FBMC 15.04.040/.050, Ord. 1022, 26 May 2026, amending CBC/CRC Sec. 105.5/R105.5): a permit becomes invalid if work is not commenced within 1 year (365 days) of issuance, or if a passed inspection is not obtained within every 365-day period thereafter; permits may be renewed/reinstated if expired less than 5 years. This closely mirrors the County's own Building Policy 9 (eff. 13 Mar 2026), which independently states the same 1-year/365-day/5-year figures for the areas it serves, including Fort Bragg. 85% · municipal code
• Which utility handles interconnection here? PG&E (Pacific Gas and Electric Company) is the wires/interconnecting utility for Fort Bragg. A Community Choice Aggregator (Sonoma Clean Power layered on PG&E's wires) may supply generation service for some Mendocino County accounts, but PG&E remains the interconnecting utility. 65% · city page (Utilities section, referencing PG&E)
• Where does the utility sit in the sequence? After permit -- utility interconnection/activation follows the County's final building inspection and approval. 65% · department handout

The NEC edition a jurisdiction enforces is often a cycle behind the newest one published, and local amendments sit on top of it. Rapid shutdown, conductor sizing and labelling all change between editions, so the edition in force is the first thing to establish, not the last.

• Which NEC edition is in force? California Electrical Code, 2025 Edition, Part 3 (based on the 2023 NEC as part of the 2025 Title 24 cycle) -- adopted directly by the City in FBMC 15.04.020(D), Ord. 1022, passed 26 May 2026. 92% · municipal code
• Which building code edition is in force? California Building Code and California Residential Code, both 2025 Edition (Title 24 Parts 2 & 2.5), adopted directly by the City in FBMC 15.04.020(B)-(C), Ord. 1022, passed 26 May 2026. 92% · municipal code
• Which fire code edition is in force? California Fire Code, 2025 Edition, Part 9 (Title 24) -- adopted directly by the City as 'the Fort Bragg Fire Code' in FBMC 15.05.010, Ord. 1022, passed 26 May 2026, with the Fire Chief (via the Fort Bragg Fire Protection Authority JPA) as the enforcing official. 90% · municipal code
• Are there local amendments to any of the above? Yes -- the City amends the state model codes in multiple places (e.g., FBMC 15.04.040/.050/.060 modify CBC/CRC/CEC Sections 105.3.2, 105.5, 109.6, R105.3.2, R105.5, R108.5, Annex H 80.15/80.19 with City-specific expiration/refund/extension rules; Appendix H sign provisions are also locally amended). The County separately layers its own numbered Building Policies (#1-19) covering PV/solar submittal, structural criteria and permit-status definitions on top of the state code for the areas (including Fort Bragg) it administers. 80% · municipal code
• What is the installation judged against? The 2025 California Building Code, Residential Code, Electrical Code and Fire Code as locally amended by FBMC Title 15 Ch. 15.04/15.05, plus the County of Mendocino's Building Policies (#2, #5, #9, #14) and PV Toolkit standard plans, which the County applies in practice to Fort Bragg permits. 82% · adopted department policy

Ridge setbacks and roof access pathways are fire-service requirements and they constrain the array layout. They are the most common cause of a redesign after the fire department comments on a plan set.

• What ridge setback and access pathways are required? Access pathways are referenced to California Residential Code Section 324 in the County's own Expedited PV handout, rather than restated as a locally-specific dimensional table; the roof plan must show fire classification and code-compliant access pathway locations. No Fort-Bragg-specific ridge-setback amendment was found in the City's own Fire Code chapter (15.05), which is a bare adoption with only edition/application/appeals sections. 65% · department handout

Which rapid-shutdown rule applies follows directly from the NEC edition in force, and the initiation device has to be at a location the fire service can reach and identify. This is inspected, and it is labelled.

• Is rapid shutdown required, and to which NEC edition? Rapid shutdown is required as a function of the statewide California Electrical Code (2025 Edition / effectively 2023 NEC Section 690.12), adopted directly into FBMC 15.04.020(D). No City or County document in the corpus I fetched cites '690.12' or 'rapid shutdown' by name. 55% · municipal code

The NEC sets a baseline for permanent markings at the service equipment and the disconnecting means. On top of that, an authority may specify its own wording, and the utility may specify more again. Where any of them writes its own text, a generic off-the-shelf label set will not pass — this is the detail most often fixed on a return visit.

• Which placards does this authority require at the service equipment? At minimum, three signs: (1) identifying PV power-source system attributes at the DC disconnect, (2) identifying the AC point of connection, (3) identifying the switch for the alternative power system. PG&E separately requires its own 'UTILITY AC DISCONNECT SWITCH' label at its own disconnect (see q42). 88% · adopted department policy (Building Policy 14)
• Does the authority specify placard wording of its own? Partially -- the County specifies what each required sign must identify (DC disconnect attributes, AC point of connection, alternate power switch) but does not mandate exact verbatim wording of its own, unlike PG&E's exact wording for its own utility disconnect label. 68% · adopted department policy
• Does it specify letter height, colour or material? No City or County document fetched specifies letter height, colour or material for the AHJ-required signs as a hard requirement (the 2015 PV Toolkit guide describes sign function only). PG&E separately mandates a hard minimum of 3/8" all-capital lettering, engraved phenolic or ANSI Z535.4-compliant, for its own utility disconnect label (utility-level, not AHJ -- see q42). 55% · adopted department policy
• Is a site plan / facility map placard required, and what must it show? Yes -- a roof/site plan (facility-map equivalent) is required showing panel/module layout, north arrow, lot dimensions, distance to property lines/structures, PV fire classification, clear access pathways, and locations of all required labels/markings and electrical disconnects/roof access points. 85% · department handout
• Does the UTILITY specify placards beyond the AHJ's? Yes -- PG&E's own Distribution Interconnection Handbook document (Greenbook doc 060559, 'Disconnect Switch Requirements for Distributed Generation Customers,' Rev. #07, approved 25 Mar 2022) requires a permanently attached label reading e.g. 'UTILITY AC DISCONNECT SWITCH,' engraved phenolic or ANSI Z535.4-compliant, minimum 3/8" all-capital lettering -- beyond and in addition to the AHJ's own three signs (q38). PG&E is the interconnecting utility for Fort Bragg (see q22). 85% · utility interconnection handbook (PG&E Greenbook doc 060559, Rev. #07, 3/25/2022)
• Where must the labels be placed? AHJ level: at the DC disconnect, at the AC point of connection, and at the alternate-power-system switch. Utility (PG&E) level: the AC disconnect label must be on the front of the switch, and the switch itself must be within 10 feet and in line of sight of PG&E's meter, at the same grade level as the meter, mounted 48"-75" high if wall/pad-mounted, never on a roof or a floor above grade. 78% · adopted department policy + utility interconnection handbook (PG&E)

Where the AC disconnect must sit relative to the meter is usually the utility's rule, not the building department's. Battery storage frequently carries its own permit, its own inspection and its own fire conditions.

• Where must the AC disconnect be, relative to the meter? Within 10 feet, in line of sight, of PG&E's electric meter; at the same grade level as the meter if outdoors; mounted 48"-75" high if wall- or pad-mounted; never on a roof, an upper floor, or inside a non-approved meter room. 75% · utility interconnection handbook
• Must equipment be on a specific approved list? Yes -- equipment must be listed/labeled for its PV application (CEC 690.4(D)); equipment cut sheets for inverters, modules, disconnects and combiner boxes are a required submittal item. This is the statewide CEC listing requirement rather than a County- or City-specific approved-products list. 80% · department handout
• Are batteries permitted, and under what conditions? Yes, with conditions -- battery storage disqualifies a project from the expedited/over-the-counter PV track, but batteries are explicitly accommodated in the standard submittal: Building Policy 14 requires 'Battery storage details, if applicable, including location and venting' on the electrical diagram, and defines both 'Grid-Connected System' and 'Stand-Alone Solar Power System... typically incorporating battery storage.' 85% · adopted department policy
• Is there a separate ESS permit or inspection? No standalone 'ESS permit' was identified -- battery/ESS installation is folded into the standard Building Permit/inspection process described in Building Policy 14, not a separately named permit type. The Building Permit Application form itself has no distinct ESS/battery checkbox (only 'Photovoltaic'). 60% · department-hosted permit application form
• Is a ground mount treated as a structure? Yes -- a ground-mounted PV system requires foundation/footing plans and reinforcement details, with a California-licensed engineer's approval mandatory for arrays exceeding 7 feet in height. 88% · adopted department policy
• Is there a local rule on service upgrades or busbar sizing? Yes -- County Building Policy 2 (Utilities & Service Connections, eff. 10 Mar 2026): a single-family residence must have a minimum 100A, 3-wire service (CEC 230.79(c)); any new panel over 200A requires load calculations/line drawings from a CA-licensed electrical contractor or engineer; amperage must be justified from existing loads only. 85% · adopted department policy (Building Policy 2, eff. 10 Mar 2026)
• Is a specific mounting system or attachment spacing required? Yes -- prescriptive anchor/attachment spacing tables (Structural Criteria, PV Toolkit Doc #5): e.g. up to 6'-0" horizontal anchor spacing at 24" rafter spacing on flat-to-6:12 roofs, tightening to as little as 1'-4" on steeper slopes (7:12-24:12); truss rules require 6' spacing generally or 4' alternating spacing where truss spacing is 16" o.c. or splice locations cannot be confirmed. 88% · department handout (PV Toolkit Document #5)

Booking is a portal, a phone call or an email depending on the authority, and the notice required is rarely zero. Book before the work is finished rather than after — the lead time, not the work, is usually what sets the date.

• How is an inspection booked? Phone (automated inspection request line, separate Ukiah/Fort Bragg numbers -- Fort Bragg: 707-961-2677 per the 2015 guide, or 707-964-5379/964-5379 general office line) or Portal (e-TRAKiT online scheduling). 85% · department handout
• How much notice is required? By 3:00 PM the business day before the requested inspection (effectively 1 business day's notice). 82% · department page (fetched via Wayback capture; direct access returned HTTP 403/Akamai block)
• Are same-day or AM/PM windows offered? AM/PM windows are attempted but not guaranteed; the department publishes a fixed weekly inspection-day rotation for the Fort Bragg/coastal area ('Fort Bragg: Monday through Friday' per the current inspection-area table). 75% · department page (fetched via Wayback capture)

Some authorities inspect their own solar work; some delegate it, and a few do not inspect the PV equipment itself at all. Who is coming determines what they will look at.

• Does this AHJ perform its own final solar inspection? Yes, in effect -- Mendocino County Planning & Building Services performs the final solar inspection for Fort Bragg addresses under the delegation described in the jurisdiction block; the City itself has no Building Inspector on staff. 78% · department page (fetched via Wayback capture)
• If delegated, to whom? Delegated -- to Mendocino County Planning and Building Services (Building Division), which self-performs inspections for the unincorporated county plus the cities of Fort Bragg and Point Arena. 80% · department page (fetched via Wayback capture)

A rough-in or mid-roof inspection, where one is required, has to happen before the work it covers is closed up. Missing a stage means opening something back up, and it is the most expensive kind of correction.

• Which inspections are required, and in what order? At minimum a final inspection is required before activation. Ground-mount or larger installs also require a foundation/footing inspection (Building Policy 14 Section 4.1) prior to final. 75% · adopted department policy
• Is a rough-in or mid-roof inspection required? Not clearly a universal requirement for a simple rack-only rooftop retrofit; a foundation/footing inspection is required for ground-mount arrays (Building Policy 14, Section 4.1), and the City's separate roofing policy (Building Policy 5) requires a roof-sheathing nailing inspection where new sheathing is involved in a re-roof. 55% · adopted department policy (Building Policy 5, eff. 10 Mar 2026)

The approved plan set, the permit, and the equipment listings should be on site and reachable. Inspectors routinely verify that installed equipment matches what was approved, and that the labels are the ones the plan set promised.

• Is there a published inspection checklist? Yes -- inspection checklists are embedded directly in the 2015 PV Toolkit guide and current Building Policy 14 (Sections 4.1-4.4), both fetched and read in full. 85% · adopted department policy
• What must be on site at inspection? The approved job-copy plans and the permit itself must be on site for the inspector to review; permit holders must be prepared to show conformance with all requirements in the field at the time of inspection. 82% · department handout
• Does the inspector verify labels and listings? Yes -- the inspector verifies module/inverter make-model against plans and spec sheets, equipment listing/labeling, and that installed signage matches equipment ratings (inverter voltage rating vs. sign, OCPD ratings vs. sign, etc). 88% · adopted department policy

Passing gives you a final or an equivalent sign-off. That is not the same as permission to operate: PTO comes from the utility, and who tells the utility the inspection passed varies. A system left switched off for weeks is usually waiting on this handover.

• What is issued on pass? Final approval / 'activation,' rather than a certificate of occupancy, green tag, or letter, is the closest match for a solar-only permit. 75% · department handout
• Who notifies the utility for PTO? Installer -- consistent with standard California interconnection practice, the installer/customer submits the PTO paperwork to PG&E once the County has granted final inspection approval; no Fort Bragg or Mendocino County document names who specifically contacts PG&E. 50% · department handout
• How are corrections issued and cleared? Corrections are issued via a written correction/revision process; a 'Correction Letter' status is defined in the County's own permit-status framework (issued when at least one division has 'corrections' noted in the plan-review table), and revisions to an active permit extend the permit 180 calendar days from submittal. The City's own code (FBMC 15.04.040/.050) contains a parallel 'submittal of revisions... shall extend the building permit 180 calendar days' provision. 78% · adopted department policy (Building Policy 9, eff. 13 Mar 2026)
