City of Madera

A city address is usually permitted by the city, not the county — but not always, and some authorities keep building and hand electrical to someone else. Getting this wrong costs the whole submittal, because every requirement below belongs to whoever actually holds jurisdiction. Check the overlays in the same pass: an HOA, a historic district, a windstorm certification or a system-size cap can reshape the design, and all of them are cheaper to find now than after the array is laid out.

• Is this authority the AHJ for residential solar at this address? Yes 97% · municipal ordinance
• What does this authority permit itself, and what does it delegate? Both 88% · department page
• Is a permit required for a residential rooftop PV system? Yes 99% · ordinance
• Is there a separate electrical permit, or is it combined? Combined 60% · department page
• Is a HOA or architectural approval required first? No city-imposed requirement found 65% · code search (absence)
• Is there a historic-district review? Yes, conditionally 92% · ordinance
• Is a Specific Use Permit or Council approval ever required? Yes, conditionally — an Administrative Use Permit (not a full Council/Specific Use Permit) may be required if the Chief Building Official finds, on substantial evidence, a specific adverse impact on public health/safety; appealable to the Planning Commission. 90% · ordinance
• Is there a system-size cap on residential generation? No hard cap on residential systems overall; the 10 kW AC / 30 kW thermal threshold in Ch. 9-4.02(B)(1) only defines eligibility for the expedited Chapter 4 review path — larger residential systems remain permittable through standard (non-expedited) plan review. 82% · ordinance

Several authorities require the electrical permit to be pulled by a licensed electrician, or require the contractor to be registered with them BEFORE applying. Registration is not same-day. This is second on the list rather than fourth because it is the step most likely to stop the job before the drawings matter.

• Who is allowed to pull the electrical permit? Either 82% · department page
• Is a homeowner permitted to self-install and self-permit? Yes 85% · department page

Almost everywhere wants a site plan, a one-line or three-line electrical diagram, equipment cut sheets with listings, and a structural attachment detail. Build it against the published checklist rather than the last jurisdiction you worked in — the checklist is what the reviewer marks against.

• What documents make up a complete submittal? Permit application + construction documents: cover sheet (address, vicinity map, owner/designer info, scope of work), site plan, roof/fire-setback plan, structural details, electrical single-line diagram + calcs, labeling plan, and manufacturer data sheets/UL listings for all major components. 96% · department page / published checklist
• How many copies, and in what format? Electronic PDF submittal is now the standard format (Electronic Plan Check Program mandatory as of 19 Dec 2024, min. 11x17 page size, one-sided). The older Solar Permits page still describes an alternate hard-copy route of two complete sets if hard-copy plans are submitted. 85% · department page
• Is a site plan required, and what must it show? Yes — must show lot/property lines, footprint of existing residence and structures, labeled streets, north arrow, and the location of all equipment/system components (modules, inverters, panels, RSDs, disconnects, existing PV). 96% · published checklist
• Is a one-line / three-line diagram required? Yes 97% · published checklist
• Are string and conductor calculations required? Yes 96% · published checklist
• Is a structural PE stamp required, and at what threshold? Required only when the structural plan sheets are prepared by a design professional (CA-licensed PE) — no separate weight/size threshold is stated; if plans are instead prepared and signed by a licensed A/B/C-46/C-10 contractor, no PE stamp is required. 78% · published checklist
• Is an electrical PE stamp required, and at what threshold? Same pattern as structural: an electrical PE stamp is only implicated if a licensed electrical engineer prepares the plans; contractor-signed plans (with license number) are otherwise accepted without a threshold-based PE trigger. 72% · published checklist

Most authorities now take the whole application through a portal, and several states cap or constrain what a residential solar permit may cost. Check whether plan check is billed separately before you quote the job.

• Which permit portal does this authority use? SolarAPP+ (via gosolarapp.org) for eligible residential rooftop PV; non-eligible/standard submittals go through email (pvplanpermits@madera.gov) or in-person/Dropbox — no separate general e-permitting portal (e.g., Accela) was identified. 90% · portal landing page
• Can the whole application be completed online? Yes, for SolarAPP+-eligible systems (fully online at gosolarapp.org); non-eligible systems use email/in-person submittal, not a self-service online application. 88% · portal
• What does a residential solar permit cost? $439.43 flat (electrical 'Photovoltaic Systems' fee) 50% · fee schedule (PDF)
• How is the fee calculated? Flat 55% · fee schedule (PDF)
• Is there a separate plan-check fee? Yes 78% · ordinance + fee schedule

Interconnection is a separate process from the permit and usually the longer pole. Where the utility does not depend on the permit being issued, running both at once is the single biggest saving available on a residential job.

• What is the stated plan-review turnaround? Same day for over-the-counter applications; 1-3 business days for electronic applications (small residential rooftop solar, Ch. 9-4.06(A)); SolarAPP+-eligible systems are effectively automated/instant. 92% · ordinance
• How long is an issued permit valid before it expires? Likely 180 days (the 2022 CBC's standard permit-expiration provision), by default of blanket code adoption. 45% · ordinance (inferred)
• Which utility handles interconnection here? Pacific Gas & Electric (PG&E) 70% · county page + utility-territory sources

The NEC edition a jurisdiction enforces is often a cycle behind the newest one published, and local amendments sit on top of it. Rapid shutdown, conductor sizing and labelling all change between editions, so the edition in force is the first thing to establish, not the last.

• Which NEC edition is in force? 2020 NEC (via the 2022 California Electrical Code) 75% · adopting ordinance
• Which building code edition is in force? 2022 California Building Code (based on the 2021 IBC) 78% · adopting ordinance
• Which fire code edition is in force? 2022 California Fire Code (based on the 2022 IFC) 78% · adopting ordinance
• Are there local amendments to any of the above? Yes 90% · ordinance
• What is the installation judged against? The city-adopted 2022 CRC/CBC/CEC/CMC/CPC/CFC/CGBC (Title 24, with the local amendments above) plus Madera Municipal Code Ch. 9-4 and the city's own solar submittal checklist. 90% · department page

Ridge setbacks and roof access pathways are fire-service requirements and they constrain the array layout. They are the most common cause of a redesign after the fire department comments on a plan set.

• What ridge setback and access pathways are required? Fire setbacks from ridges/hips/valleys (with dimensions shown) plus two 36"-minimum access pathways (one from the street side, in front of any fence), sited to support firefighter access and clear of obstructions; PV coverage % of roof plan-view must be indicated and fire-sprinkler status noted. 95% · department page / local amendment

Which rapid-shutdown rule applies follows directly from the NEC edition in force, and the initiation device has to be at a location the fire service can reach and identify. This is inspected, and it is labelled.

• Is rapid shutdown required, and to which NEC edition? Yes, required to 2022 CEC (2020 NEC base), §690.12/690.56 88% · published checklist

The NEC sets a baseline for permanent markings at the service equipment and the disconnecting means. On top of that, an authority may specify its own wording, and the utility may specify more again. Where any of them writes its own text, a generic off-the-shelf label set will not pass — this is the detail most often fixed on a return visit.

• Which placards does this authority require at the service equipment? A directory/placard showing the location of the array(s), equipment, and point of connection; plus standard NEC/CEC-mandated service-equipment labels (no separate itemized city placard list beyond this was found). 78% · published checklist
• Does it specify letter height, colour or material? Colour is specified ('Show all applicable labeling in color'); no letter-height or material specification was found in any Madera source reviewed. 65% · published checklist
• Is a site plan / facility map placard required, and what must it show? Yes — a directory placard is required showing the location of array(s), equipment, and point of connection. 85% · published checklist
• Where must the labels be placed? At the service equipment / disconnects / point of interconnection, with array, equipment, and POI locations shown on the site plan; no more granular city-specified placement rule (e.g., distance from meter) was found. 62% · published checklist

Where the AC disconnect must sit relative to the meter is usually the utility's rule, not the building department's. Battery storage frequently carries its own permit, its own inspection and its own fire conditions.

• Must equipment be on a specific approved list? Yes 88% · published checklist
• Are batteries permitted, and under what conditions? Permitted; must be described and documented on the plans (data sheets required for any new/existing energy storage system) but no Madera-specific ESS ordinance or local amendment was found — ESS installations appear to be governed entirely by the state-adopted 2022 California Fire Code (which contains its own ESS chapter) without a city-specific overlay. 68% · code search (absence) + fire code cross-reference
• Is a ground mount treated as a structure? Not explicitly classified in any Madera-specific text found; by default, a ground-mounted PV array with a foundation/anchoring would fall under the general CBC definition of 'structure' as adopted at §9-1.02, since no zoning exemption was located. 50% · code search (absence) + general ordinance inference
• Is a specific mounting system or attachment spacing required? Yes — max 6 ft horizontal anchor spacing (shown on plans), min 5/16" lag screws with min. 2-1/2" embedment into rafters (pre-drilled holes), 2"-10" standoff from roof surface, max 4 lb/sq ft system weight, single roofing layer only, no ballast/counterweight systems. 96% · published checklist

Booking is a portal, a phone call or an email depending on the authority, and the notice required is rarely zero. Book before the work is finished rather than after — the lead time, not the work, is usually what sets the date.

• How is an inspection booked? Phone 95% · department page
• How much notice is required? Effectively about 1 business day: requests made before 4:00 p.m. are scheduled for the next business day; requests after 4:00 p.m. are scheduled for the 2nd business day following. 90% · department page
• Are same-day or AM/PM windows offered? AM (8:00-12:00) / PM (1:00-4:00) preference may be requested but is not guaranteed; no same-day inspection option is offered. 90% · department page

Some authorities inspect their own solar work; some delegate it, and a few do not inspect the PV equipment itself at all. Who is coming determines what they will look at.

• Does this AHJ perform its own final solar inspection? Yes 95% · department page
• If delegated, to whom? N/A — not delegated; the City's own Building Division performs the inspection. 90% · department page

A rough-in or mid-roof inspection, where one is required, has to happen before the work it covers is closed up. Missing a stage means opening something back up, and it is the most expensive kind of correction.

• Which inspections are required, and in what order? For Ch. 9-4/expedited (small residential rooftop) systems: a single consolidated final inspection ('Only one inspection shall be required and performed... for small residential rooftop solar energy systems eligible for expedited review,' Ch. 9-4.06(G)-(H)). No separate rough-in stage is described for this track. 85% · ordinance
• Is a rough-in or mid-roof inspection required? No, for Ch. 9-4/expedited-eligible small residential systems — the ordinance caps this at one required inspection. Not established for larger/non-eligible systems. 78% · ordinance

The approved plan set, the permit, and the equipment listings should be on site and reachable. Inspectors routinely verify that installed equipment matches what was approved, and that the labels are the ones the plan set promised.

• Is there a published inspection checklist? Yes 92% · department page
• What must be on site at inspection? Inspection card, set of approved plans, and all supplementary documents; for SolarAPP+ jobs specifically: printed Permit, Approval Document, Inspection Checklist, and equipment specifications. 95% · department page
• Does the inspector verify labels and listings? Yes (inferred) 62% · department page (inferred)

Passing gives you a final or an equivalent sign-off. That is not the same as permission to operate: PTO comes from the utility, and who tells the utility the inspection passed varies. A system left switched off for weeks is usually waiting on this handover.

• Is there a re-inspection fee? $87.89 per hour 50% · fee schedule (PDF)
• How are corrections issued and cleared? A written correction notice detailing all deficiencies is issued to the applicant for resubmission/cure; inspectors can be reached directly for questions on a correction notice. 85% · ordinance
