Label
050-01 PV System Disconnect Label
Made in USA
NEC Compliant
Ships same day
Solar PV disconnect label with red background and white letters (3″ x 0.375″). Made in the USA with UV-resistant, NEC-compliant, outdoor rated Avery Dennison® MPI Hi Tack Easy Apply™ vinyl. The sign reads: 'PV SYSTEM DISCONNECT'. This label is available as a red label and red placard. This label is used on micro inverter and dc strings solar installations
NEC Articles
- 690.13(B)
Code years covered
- NEC 2017 — required
- NEC 2020 — required
- NEC 2023 — required
| Width | 3″ |
| Height | 0.875″ |
| Background | Red |
| Letters | White |
| Finish | Gloss laminate |
| Material | Avery Dennison® MPI Matte Opaque Hi Tack Easy Apply™ |
| Adhesive | Exceptionally strong long-life outdoor adhesive |
| Origin | USA |
| UV Stable | YES |
| Weatherable | YES |
Available variants
